High-strength shipbuilding steel that meets the CCS classification society's certification standards
If you are looking for reliable steel for ship hull structures, dock maintenance or marine engineering, our CCS A shipbuilding steel plate are your ideal choice. As a professional steel exporter, we are well aware of the harshness of the marine environment. Each steel plate is produced strictly in accordance with the specifications of the China Classification Society (CCS) to ensure excellent performance even in extremely cold, highly corrosive and high-intensity impact conditions.
Obtain the latest shipboard quotation sheet & factory direct price
Why choose our shipbuilding steel plates?
Quality Assurance
Source control: We only use the continuous casting billets from top domestic steel mills as raw materials and strictly refuse to use recycled scrap steel as the base material.
Physical inspection: 100% ultrasonic testing is conducted before leaving the factory to ensure there is no layering or bubbles inside.
Mechanical properties: For each batch, the test block data from tensile and impact tests are retained. The original warranty certificates can be provided at any time.
Traceability: The surface of the steel plates is marked with steel stamps, clearly indicating the furnace number, batch number, specification, and CCS certification mark. Even after cutting, the remaining parts can still be traced back to their source, which is a key aspect of compliance in shipbuilding construction.
Product basic information
| Parameter Details | Why is it important? | |
|---|---|---|
| Standard | CCS A (China Classification Society Grade A) | The globally recognized "passport": Obtaining CCS certification means that the steel has passed the strict review of the global maritime industry, and it can be smoothly inspected by the ship surveyors, avoiding the risk of being rejected by the ports. |
| Size | Thickness：6mm - 150mm Width：1500mm - 4000mm Length：6000mm - 12000mm |
Precise cutting, reducing waste: We offer flexible fixed-length cutting services. We can customize the size according to your drawings, helping your shipyard save at least 5% of welding and cutting costs. |
| Chemical composition | C ≤ 0.21% Si ≤ 0.35% Mn ≤ 2.5% P and S impurities are extremely low. |
Innate "corrosion-resistant constitution": We strictly control the content of sulfur (S) and phosphorus (P). This ensures that the steel plates have better resistance to laminar tearing, and even when exposed to seawater for a long time, they are less likely to develop cracks. |
| Mechanical properties | Yield strength ≥ 235 MPa Tensile strength 400 - 520 MPa Elongation rate ≥ 22% |
A balanced sense of security: The high yield strength means it can bear the weight of large ships; while the high elongation rate indicates that it is not "brittle steel", and has better resilience in collisions or extreme waves, thus safeguarding the safety of the ship's structure. |
| Impact test | 0°C Longitudinal Impact (27 Joules) | The "Guardian" against the cold: The CCS A-level standard requires that this steel plate can still absorb a large amount of energy at 0°C. No matter whether your vessel is sailing on the Arctic route or in tropical waters, this steel plate can maintain stable physical properties. |
What scenarios are CCS A shipbuilding steel plates mainly used for?
Main structure of the hull
This includes the bottom plate, side plates, and deck, which are large components that bear the main stresses.
Ship Maintenance and Refitting
For the replacement of steel plates during the dry-docking period of old ships, our fixed-length cutting service can significantly shorten the ship repair cycle.
Barges and floating docks
Suitable for the construction of various inland river and offshore barges, with extremely high cost-effectiveness.
Marine engineering equipment
Modules for drilling platforms, port machinery, etc., require support structures made of high-strength steel.
who choose us?
Factory direct operation/deep cooperation: There are no middlemen involved in the profit margin. For large-tonnage orders, we can offer a flexible payment method of 30% advance payment + 70% payment upon receipt of the copy of the bill of lading, helping to alleviate your financial pressure.
One-stop service: From the domestic port to the destination port, we offer a full range of services including export customs declaration, fumigation of wooden pallets, and marine insurance. We also support third-party inspections (SGS/BV/ship inspectors).
one-stop solution
professional team
high quality
our Partners
We trusted by
User Evaluation
Mr. Chen Wei
Singapore · Large Shipbuilding and Repairing Group
Ms. Nguyen Thi Hong
Haiphong · Shipbuilding Group of Vietnam
Mr. Rajesh Kumar
Kochi, India · Ship Repair Yard
FAQ
01.What are the differences between CCS A steel plate and ordinary carbon structural steel (such as Q235B)?
CCS A: Each batch of steel must be factory-approved by the China Classification Society (CCS). Each batch number has its own ship inspection certificate, and the surface of the steel plate must have a steel stamp marking (including the batch number, batch code, and certification mark). When the ship inspector conducts the acceptance at the shipyard, they only recognize the steel plates with the steel stamp and the quality guarantee certificate.
Ordinary carbon steel: Without classification society endorsement, it cannot be used for the main structure of the ship.
In simple terms, using non-steel plates as substitutes will directly result in the rejection of the ship inspection, and even affect the issuance of the ship launching permit.
02.Which quality documents will be included with the goods? Can the electronic versions be provided for advance review?
CCS Factory Certification (Copy, with official seal)
Material Certificate (Mill Test Certificate): Includes furnace number, batch number, chemical composition, and measured values of mechanical properties, in compliance with EN 10204 3.1 standard.
Weight list and packing list
Third-party inspection report (if requested by the customer for SGS/BV inspection)
All the documents can be provided before shipment. High-resolution scans are available for your pre-review. Once you confirm that they are correct, we can proceed with the shipment.
03.What is the thickness range of the CCS A ship plate? Can it be processed into special-shaped parts?
04.What is the condition of the surface of the ship plate? Has it undergone rust prevention treatment?
05.What is the typical delivery period? How can we ensure timely shipment?
