China Customized Wear Resistant Steel Plate Suppliers - Wholesale Service

Large Stock Of Hardox 450 Wear-resistant Steel Plate
What Is Hardox 450 wear-resistant steel plate Wear-resistant steel is a special kind of steel that is mainly used to make mechanical parts and tools that work under harsh wear conditions. The main characteristics of wear-resistant steel
read more
Large Stock Of Hardox400 Wear-resistant Steel Plate
Products Description The HARDOX 400 has excellent weldability. Parameter
read more
Hot-rolled Coil
It is often used in the steel industry and is distinguished from hot-rolled coils. It refers to the steel strip directly rolled into a certain thickness by a roll and rolled into a whole coil by a winder at normal temperature.
read more
Hot Rolling
HRB stands for hot-rolled Ribbed Bar, namely Hot rolled Ribbed Bar, the so-called ribbed bar refers to the surface of the steel bar rolled by hot rolling process deformation to increase the bite force between the concrete, including the
read more
Hot Rolled Plate
Size specificationThe size of the steel plate shall comply with the provisions of the table Size Specifications of Hot rolled steel plates (from GB/T709-1988).The size of the steel strip shall comply with the provisions of the table Size
read more
HARDOX Series Wear-resistant Plates
HARDOX series wear-resistant plates are HARDOX 400, HARDOX 450, HARDOX 500, HARDOX 550, HARDOX 600 grade steel. This standard wear-resistant steel plate has a feature of low carbon content, which improves its toughness and impact
read more
Bimetal Clad Wear-resistant Steel Plate
The main chemical composition of wear-resistant composite steel plate is C (%): 3.0-5.0, Cr (%): 25-40. The chemical composition can produce a large amount of chromium carbide particles Cr7C3. The hard chromium carbide particle material is
read more
1E1839 Steel Plate
1E1839 steel plate is a special quenched and tempered steel for Caterpillar, the world's largest construction machinery manufacturer. Later, because of its better comprehensive performance in all aspects, the steel plate was unanimously
read more
NM450 Steel
High strength: NM450 wear-resistant plate has high strength, can withstand greater force, and has excellent tensile strength and compressive strength
read more
NM500 Steel
NM500 wear-resistant steel plate is widely used in engineering machinery, environmental protection machinery, metallurgical machinery, grinding tools, bearings and other product parts.
read more
Surfacing Wear-resistant Steel Plate
Hardfacing wear-resistant steel plate,often referred to as high-chromium wear-resistant steel plate, is a high-performance composite steel plate that resists wear. Through surfacing technology, it blends the high chromium alloy layer with
read more
BHNM450 Wear-resistant Plate
BHNM450 wear-resistant plate is composed of low carbon steel plate and alloy wear-resistant layer. The alloy wear-resistant layer is generally 1/3~1/2 of the total thickness. During operation, the matrix provides comprehensive properties
read more

First 12 Last

Introduction of Wear Resistant Steel Plate

Also known as abrasion-resistant steels are quenched steels to obtain hard martensitic microstructure. Due to high hardness, they have high mechanical properties which allow them to increase the lifetime of wear parts as well as significantly decrease the weight of equipment. Despite high hardness, abrasion-resistant steels can be bent, welded, cut, and machined with all common methods. There are several grades of abrasion resistant steel, including AR200, AR235, AR400, AR450, AR500 and AR600.

Composition of Wear-Resistant Steel Plates

Different ingredients and components are used to create various wear-resistant plates. Abrasion-resistant steel plates with integrated composites following heat treatment. The most typical and typical, nonetheless, are:

Carbons
Iron
Other Alloy Types Chromium
Depending on the use and functionality, these come in various sizes and grades.

Advantages of Using Abrasion Resistant Wear Plate

Durability
Abrasion-resistant wear plates are highly durable and can withstand heavy impact and abrasion. They are made of a special type of steel that is much harder and stronger than regular mild steel. This makes them ideal for construction and infrastructure projects where the equipment must constantly be exposed to harsh conditions.

Increased Lifespan
Using abrasion-resistant wear plates can significantly increase the lifespan of construction and infrastructure equipment. The wear plates protect the underlying structure from damage, corrosion, and erosion. This means the equipment will last longer and require fewer repairs and maintenance.

Reduced Maintenance Costs
As mentioned earlier, using abrasion-resistant steel wear plate can reduce the need for repairs and maintenance. This can save construction companies much money in the long run. In addition, these plates are easy to replace, so any damaged plates can be replaced quickly and easily.

Improved Safety
When equipment is exposed to heavy impact and abrasion, there is always a risk of accidents. However, the use of abrasion-resistant wear plate can significantly reduce this risk. This is because the plates provide an extra layer of protection, which can prevent accidents and injuries.

Better Performance
Abrasion resistant steel wear plates can improve the performance of construction and infrastructure equipment. This is because the plates reduce the amount of wear and tear on the equipment, which means that it can operate more efficiently. This can lead to increased productivity and lower operating costs.

Common Applications of Wear Resistant Steel Plate

Construction and Mining Industry
Construction and mining industries use equipment subjected to wear and tear, so the required equipment must be sturdy and long-lasting. Wear-resistant steel plates can be used in various mining and construction equipment, such as wear liners, rock breakers, bulldozers and excavator bucket liners. They are ideal for this industry because they have high strength, which means they can withstand heavy impacts. The use of wear-resistant plates helps increase the lifespan of the equipment while maintaining its efficiency.

Transportation and Automotive Industry
Wear-resistant steel plates also find their use in the transportation industry. Many parts of vehicles, such as bulldozers, lorries, trailers, and dump trucks, are exposed to harsh conditions, requiring frequent repairs. Wear resistant plate can significantly reduce maintenance costs in the transportation and automotive industry.

Agriculture and Farming Industry
The agricultural industry involves heavy machinery and equipment that is regularly used. Wear-resistant steel plate can be utilized in machinery parts such as crop harvester blades and chutes that receive heavy impact, soil tilling equipment and plowshares that experience high resistance levels. These plates help prolong the lifespan of machinery parts, and thus, they benefit the agriculture and farming industry by keeping the cost of maintenance low.

Energy and Power Generation Industry
The energy and power generation industry also benefits from using wear-resistant plate. Regular wear and tear of the machinery are the main concerns of this industry. The parts, such as boiler blades, turbines and hoppers, can experience corrosion and wear due to constant use. The use of wear-resistant plate helps reduce downtime, increases the lifespan of equipment, increases productivity, and keeps maintenance costs low.

Steel and Cement Industry
The steel and cement industry works with high temperatures, heavy machines, and heavy materials, hence the need for high-strength wear-resistant plates that withstand such pressures. These steel plates are used in cement and steel mills’ liners, buckets, hoppers, and chutes. They help reduce downtime and repairs and increase the lifespan of machinery and equipment.

How are Wear-Resistant Steel Plates Created

Melting and Mixing
The first step in creating abrasion resistant steel plates is melting and mixing the raw materials. The raw materials typically include iron ore, coal, and limestone, as well as various alloys that are added to increase the hardness and toughness of the steel.

Casting
After the raw materials have been melted and mixed, the steel is cast into large slabs or billets. These slabs or billets are then heated and rolled into thinner sheets or plates.

Heat Treatment
Once the steel has been rolled into plates, it is subjected to a heat treatment process. This process involves heating the steel to a high temperature and then rapidly cooling it.

Quenching and Tempering
After the heat treatment process, the steel is quenched and tempered. Quenching involves rapidly cooling the steel to room temperature, which increases its hardness. Tempering involves reheating the steel to a lower temperature, which increases its toughness.

Cutting and Finishing
After the quenching and tempering process, the steel plates are cut and finished to the desired size and shape. This may involve cutting the plates to a specific length or width, or it may involve adding additional finishing touches, such as beveling or chamfering the edges.

What Factors Will Affect the Quality of Wear-Resistant Steel Plates

Factor 1: Heat Treatment & Alloy Content
Wear-resistant steel plates are well defined regarding their hardness. There are mainly 2 ways to increase the hardness and toughness of the wear plates:
Heat Treatment (QT): For some specific working environments, such as earthmoving and mining, quenched and tempered steels by the process of heat treatment are an economical choice. However, these types of wear plates, while cost effective, are not as durable as alloy wear plates.
Adding Alloy Content: For alloy wear plates, there are 3 basic alloying elements: carbon, silicon, manganese, and of course, other alloying elements can also improve different mechanical performances of wear-resistant steel plates:
Carbon: The increase of carbon content in steel will increase its yield point and tensile strength but reduce its ductility and impact. Meanwhile, too much carbon content could reduce the weldability of the steel, so adjusting the carbon content balance in the wear plate is a very important operation that can’t be ignored.
Silicon: Silicon can significantly increase the elastic limit, yield point and tensile strength of steel, but like carbon, the weldability of steel would decrease by adding too much amount of silicon.
Manganese: Manganese is a good deoxidizer, and desulphurization in the steelmaking process, so that the wear plate has greater strength and hardness, also improves the hardenability of steel and the hot processing performance.

Factor 2: The Smoothness of the Surface
When considering the lifespan of the wear-resistant steel plates, especially in applications like the truck bodies, conveyor belts, and fan blades, the smoothness of the surface is a very critical factor. A smooth surface can ensure uniform wear as well as bending radius, which can provide a precise bending accuracy.

Factor 3: Hardness Variations within the Plate
The core hardness value affects the lifetime of the wear parts, for example, as wear occurs and new material is exposed, if the core hardness value of the steel plate is higher, the wear rate will be minimized compared to the steel plate with a low core hardness value, and the service life of the parts will also be prolonged.

How to Choose the Best Wear Plates for Your Project

Understanding Wear Plates

Before you start selecting wear plates for your project, it’s essential to understand what they are and how they work. Wear plates are metallic plates added to machinery surfaces to provide impact resistance, wear protection, and longer lifespan. They are made of various materials such as aluminium, bronze, carbon steel, or stainless steel, and the thickness, hardness, and impact resistance vary depending on the application.

Identifying the Wear Type

The wear your machinery or component faces is critical in determining which wear plate to choose. There are three primary types of wear: abrasive, adhesive, and erosion. Identifying the wear type and the surfaces most prone to abrasion or erosion will help you choose the type of wear plate that will offer the most effective protection.

Choosing the Right Material

The material used to make the wear plates determines their overall performance and how well they will protect your machinery. Choosing the right material depends on various factors, such as the type of wear, the environment, the temperature, the cost, and the required hardness and resilience. Some common materials used for wear plates include chromium carbide, tungsten carbide, ceramic, and cast iron.

Thickness and Hardness

The thickness and hardness of the wear plate matter as they affect the plate’s overall performance and lifespan. A thicker plate can provide better protection and impact resistance but also increase the weight and cost. The hardness of the plate determines its ability to withstand wear and tear, and different applications require different hardness levels. Choosing the right thickness and hardness will ensure that your machinery is well-protected and has a longer lifespan.

Consult an Expert

Choosing the right wear plates for your project can be challenging, especially if it’s complex and requires specialised knowledge. It’s advisable to consult an expert in wear plates and surface engineering who can assist you in identifying the best options for your project based on the wear type, material, thickness, hardness, and other factors. An expert can also advise on installing and maintaining the wear plates to ensure they work efficie

Difference Between AR400 Steel and AR500 Steel

We offer both AR400 and AR500 grades to suit any abrasion-resistant projects you may have. Although they share the important core properties of abrasion-resistant steel, the two metals have a few key differences which allows them to cover even more ground when it comes to their available applications. While AR400 is known for its workability and AR500 is known for its tensile strength, each metal contains a few other hidden advantages which can directly benefit your project in any application.

AR400 Steel

Laser Cut AR400 is workable and malleable while maintaining many of the abrasion and impact resistant characteristics that make AR steel so valuable. The addition of chromium to AR400 makes it more corrosion resistant as well, making it well suited for outdoor applications where weathering is a concern. The greatest benefit AR400 offers is its workability. Because it’s softer than most other grades of AR, it is more easily welded and manipulated without reaching the point of internal cracking or damage. Even with the added workability, AR400 is still three times harder than Mild Steel and through-hardened, so it can withstand significant impact and abuse.
Be warned, however, that while it’s one of the most workable of the AR grades, it’s still comparatively difficult to deform. Bending, rolling, and other post-processing shaping methods will take patience and significant effort.

Applications for AR400
Heavy equipment liners
Gun range targets
Mining equipment
Non-load bearing construction
Tooling/hand tools

AR500 Steel

Laser cut AR500 steel has 1.25x the tensile strength of AR400, as well as a higher yield strength and tensile modulus. This means that AR500 is overall significantly more impact resistant than AR400, and the addition of manganese increases its sheer strength. AR500 makes up for its lack of workability with high wear resistance, allowing it to withstand intense weathering and high impact environments. AR500 is best suited for applications where the main failure points are long-term wear and tear, as it’s through-hardened during the initial heating phase of its creation. With very little disruption to the consistency of its hardness throughout even the very center, AR500 is capable of taking hits from heavy machinery, abrasive rocks and minerals, and other destructive aggressors without weakening. Although AR500 is one of the lowest rated steel alloys for workability, it can be welded with some practice and patience. We cannot bend, tap, or deburr AR500 in-house, and we recommend against attempting additional machining and forming such as countersinking as it can severely damage the structural integrity of the plate. If you are looking for highly workable metals, you can learn more about the differences between those materials like aluminum and steel in our article.

Applications for AR500Combat robotics
Quarry equipment
Truck plows
Armor plating
High caliber targets
Cutting edges

Company Honor

productcate-1-1

Common Problem of Wear Resistant Steel Plate

Q: Where are wear-resistant steel plates used?

A: Thanks to their excellent hardness and toughness properties, these wear-resistant steel plates can be found in various industries and applications where abrasion, wear, tear and impact requirements are particularly critical.

Excavators, Crushers and Bulldozers
Mining and earth-moving machinery
Liners and structural elements for buckets
Dump Truck bodies
Crushing and pulverizing equipment
Conveyor belts
Fan blades
Scrap presses
Paving moulds

Unlike many other steel products, these wear steel plates doesn't have a standard provision, nor required specific chemical composition. The fact is that each mill has its own alloy composition of wear plates, resulting in different mechanical performance. But being agreed to all, the hardness which is measured in Brinell units is the most crucial factor in judging the quality of a wear plate.

Q: Do you need AR400 or an AR500 Steel Plate?

A: The application will determine whether you want an AR400 or AR500 wear-resistant steel plate. If your activities call for high wear resistance levels, you should choose AR400 steel. For instance, you can attach AR400 to tools like digger blades and similar objects. On the other hand, AR500 is ideal due to its high levels of resistance and durability. It is less suitable for high-impact applications and areas because it is harder, making it much more brittle.

Q: What is the best steel for wear resistance?

A: Among the wide varieties of wear-resistant steel, stainless steel continues to be a consumer favorite.
Stainless steel is piled on top of each other.
Stainless steel is ideal for wear resistance due to its brilliance and capacity to withstand impact, corrosion, and abrasion.
Other kinds of steel, however, work better in some circumstances. You must thus think about the use you would make of it.

Q: What is the hardest type of metal?

A: There is no definitive response to this query, although the toughest and most dependable substances include metals containing nickel and iron alloys.
Tungsten strips are among the toughest metals available.
The hardest metal, according to our formula, would be tungsten, followed by chromium.
Again, you can experiment with the many components that affect the metal’s hardness.

Q: What is through-hardening?

A: AR steel is often described as being through-hardened, but what does that really mean?
When grain structure changes during the initial heating stage of Q&T, the composition of the entire plate changes. This is referred to as through-hardening. Through-hardening differs from "case-hardening," also referred to as "surface-hardening," which only hardens the surface while allowing the metal deeper underneath to remain soft. In this case, the composition, or hardening, of the plate only changes at the surface level.

Q: What are wear resistant plates and their features?

A: A Wear-Resistant Steel Plate is made from an alloy of stainless steel that contains at least 0.2 % nickel, aluminum, or copper. It is frequently used in the manufacturing of structural components and tools. The alloy is resistant to wear, corrosion, and rust.
Steel plates that are Wear Resistant Plates (AR) are normally produced in their as-rolled condition. These steel plate product types have been created specifically for long service life in challenging environments. Tempering and quenching are used to create wear-resistant steel plates. The formation of crystal structures during the quenching process enhances the material’s strength. Steel produced using this technique has a four times greater resistance to wear.
When attempting to increase the service life of crucial components and decrease the weight of each unit placed into service, designers and plant operators use Wear-Resistant Steel Plate. There are numerous advantages to using wear-resistant plate steel in applications where there will be sliding or impact contact with abrasive material.
Wear-resistant steel plate is composed of an alloy of carbon and one or more other elements. The alloys have high hardness and offer higher strength and less weight than conventional steel. Their durability is also enhanced through heat treatment, which further increases their strength. These steels are used in heavy-duty applications such as mining. They can withstand harsh conditions and are more resistant to acidic environments than conventional steel.
Wear-resistant plates protect and secure the parts of machines. Their production process is relatively simple. They are a great investment for industries that deal with moving equipment. They are an excellent way to extend the life of your machinery.

Q: What is abrasion-resistant steel?

A: Abrasion-resistant steel, or AR steel, is mainly used for applications where abrasion and wear are the causes of failure, and not in infrastructure like buildings or bridges. Typical uses include buckets and other heavy equipment attachments, dump and trailer bodies, concrete mixers, garbage trucks, wear liners and wear parts, such as cutting edges.
AR steel plate is made from steel slabs containing different alloys. Of these alloys, carbon plays a key role in making wear plate abrasion-resistant, because it increases the steel’s hardness. When the carbon increases, the hardness increases, but the toughness is reduced making it more susceptible to cracking.
That’s why good steelmaking processes are vital. You need just the right recipe that balances alloying, heat treatment and chemistry to get the properties you want.

Q: Why are abrasion resistant steel plates important?

A: Abrasion-resistant steel plates are essential to many industrial and construction applications. These plates offer superior durability and long-lasting wear resistance, making them ideal for tough environments. Equipment and machinery would only suffer from rapid wear and tear with abrasion-resistant steel plates, leading to costly repairs and downtime. These plates also help to reduce maintenance costs and increase efficiency, allowing businesses to operate more effectively.

Q: How to choose the best abrasion resistant steel plate for your project?

A: When selecting an abrasion resistant steel plate for your project, there are several factors to consider. First, you must determine the abrasion resistance required for your application. Hardness, toughness, and strength are all important considerations when choosing a plate. The thickness and size of the plate are also critical factors to keep in mind, as they will determine the plate’s resistance to impact and wear. Another important factor to consider is the type of abrasion: sliding, impact, or heat. For instance, a plate with a higher toughness value may be required if your application involves impact. However, a harder plate may be more effective if the abrasion is due to sliding. Consider the environmental conditions in which the equipment will operate as well. A stainless steel plate may be necessary for harsh environments, such as high temperatures or corrosive substances.

Q: What is the difference between AR400 and AR500 steel?

A: While AR refers to “abrasion resistance,” the number in the grade, “400” or “500,” refers to the Brinell Hardness. AR500, therefore, has a higher Brinell Hardness than AR400.
Unlike other steels, where the primary properties taken into consideration are tensile strength or toughness, abrasion resistant steels are graded according to their Brinnell Hardness. Hardness is one of the most important factors when it comes to abrasion resistance.
Because of its impact and wear durability, AR400 is typically used when high wear resistance is a requirement, for example in digger blades and buckets, heavy machinery, and mining machinery. The addition of chromium increases its corrosion resistance, wear resistance, hardenability, and abrasion resistance.
AR500 is a medium carbon, abrasion resistant steel that is alloyed with manganese. Designed for impact resistance and wear, it has outstanding fatigue and corrosion resistance. AR500 is delivered heat treated for both hardening and better welding. Because of its durability, you’ll find AR500 frequently in truck trailers, concrete and aggregate industries, and mining equipment.
However, AR400 and AR500 aren’t so different that they aren’t interchangeable in many applications, like mining equipment, cement pouring and forming equipment, excavation equipment, and conveyor systems.

Q: What is metal abrasion?

A: When materials run against one another for an extended period of time, abrasion occurs. Sometimes, abrasion is intentional, as is the case with blasting, sanding, or grinding. But, when it’s unintentional, it can lead to structural or component failure. While steel in general stands out for its resistance to abrasion, not all steels are created equal, and some steels—abrasion resistant steels-are particularly suited for applications or environments where abrasion is expected.

Q: How is abrasion resistant steel made?

A: Like other steels, abrasion resistant steel is made from a combination of iron ore, carbon, and other alloys. First, undesirable substances are removed from the iron ore when it is melted in a blast furnace. At the same time, carbon and other alloys are added to the mix. Typically, abrasion resistant steels will be formulated with extra carbon and alloys like chromium and manganese for increased abrasion resistance. Afterwards, substances that prevent oxidation are added and the molten abrasion resistant steel is shaped, heat treated, and cut, now ready for final processing.

Q: What makes steel abrasion resistant?

A: AR steel alloys are made from billets of steel containing different alloying elements such as carbon, manganese, chrome, nickel, and boron. Of all these alloys, carbon is the most important in making steel abrasion resistant, as it increases hardness and toughness. The AR steel is then produced by “Quenching and Tempering” (Q&T), during which the grain structure is changed to increase toughness and reduce brittleness.
Q&T is a 2 stage process: Quenching occurs when the steel is brought to a temperature of around 1500 degrees F and cooled with oil, water, or air. This process increases hardness. Tempering is the process or reheating the steel to around 300-700 degrees F which allows the steel to become more ductile.
While high-carbon alloys and Q&T treatment makes steel harder, it also reduces its tensile strength. Therefore AR steels are used in situations where abrasion, wear, tear and impact are the main problem, and not constant tension or pressure. As such, AR steels are not ideal for structural construction like beams in bridges and buildings. Common uses are in buckets, grates, chutes, conveyors, ore pockets, and armor for vehicles and targets.

Q: What is wear resistance in steel?

A: Wear resistant steel generally has a higher carbon content and also contains manganese, chromium, nickel, vanadium and boron. These alloying elements increase not only the hardness but also the ductility. To a limited degree, these elements also have a positive effect on corrosion resistance.

Q: What is wear plate steel?

A: Wear plates are abrasion resistant plates or liners that are used to reduce wear and tear in surfaces that are exposed to intense rolling abrasion and impact. These plates are made fit-for-purpose for a number of machines and products across the earthmoving, mining and other industrial industries.

Q: What metal is wear resistant?

A: Wear-resistant steels often have a high proportion of carbon and manganese in their microstructure. However, the most frequently used materials for wear applications are copper alloys such as tin bronze, phosphor bronze, leaded bronze, gunmetal, brass – and aluminum bronze.

Q: What are wear resistant plates used for?

A: In addition to being used for culinary equipment and appliances, such as cutlery and plates, Wear Resistant Steel Plates are also employed in the construction of buildings and bridges.

Q: What is a high wear resistant material?

A: Carbon nanomaterials including fullerenes, CNTs, graphene, and nanodiamonds show high potential as solid additives in bulk materials for high wear resistance.
