What is the difference between P355GH and S355j2?
When engineers and procurement managers look at European standard steel grades, they often get stuck on one confusing question:
"Both P355GH and S355J2 have a minimum yield strength of 355 MPa. They look the same on paper. Can I just use whichever is cheaper or available?"
The short answer is NO.
While they share the same strength level, their DNA (manufacturing standards) , chemical composition, and performance under extreme conditions are completely different.
Selecting the wrong grade can lead to high-temperature creep failure (if you choose S355J2 for a boiler) or brittle fracture in freezing weather (if you choose P355GH for a bridge in Siberia).
In this guide, we break down the exact differences between P355GH and S355J2 so you can make the right call-and avoid legal liability or safety disasters.
The Core Difference – Pressure vs. Structure
1. Standard Specifications (The Most Critical Difference)
| Feature | P355GH | S355J2 |
|---|---|---|
| Standard | EN 10028-2 | EN 10025-2 |
| Application | Pressure vessels, boilers, heat exchangers | Bridges, cranes, buildings, wind towers |
| Key Requirement | Elevated temperature properties + rigorous NDT (non-destructive testing) | Impact toughness at -20°C only |
2. Chemical Composition Comparison
Even though both are non-alloy steels, the "recipe" varies significantly to serve different working conditions.
| Element | P355GH (Pressure Grade) | S355J2 (Structural Grade) | Why it matters |
|---|---|---|---|
| Carbon (C) | ≤ 0.18% | ≤ 0.22% | Lower carbon in P355GH = better weldability for thick walls. |
| Sulfur (S) | ≤ 0.010% | ≤ 0.035% | This is the big differentiator. P355GH has ultra-low sulfur to prevent hot cracking during welding of pressure parts. |
| Alloying elements | Micro additions of Mo (Molybdenum) , Nb | Simple C-Mn system | Molybdenum in P355GH improves high-temperature strength (creep resistance). |
Pro Insight: If your project requires Post-Weld Heat Treatment (PWHT) , P355GH is far superior. S355J2 has a higher risk of reheat cracking under PWHT.
Application Scenarios – When to Use Which?
Lorem ipsum dolor sit amet, consectetur adipiscing slit. Nunc blandit dui eget ipsum pulvinar tempor. In laoreet elit sodales, finibs lorem nec, rutrum ipsum.
P355GH Applications (High Temperature & Pressure)
The "GH" in P355GH stands for "Elevated Temperature properties" .
Boiler drums – Long-term exposure to 400°C high-pressure steam.
Oil refinery reactors – High temperature + corrosive media.
Heat exchanger shells.
LPG storage tanks (specifically for the high-strength requirement).
S355J2 Applications (Load-bearing & Cold Climates)
The "J2" in S355J2 means "27J impact energy at -20°C" .
Construction machinery – Excavator booms, crane arms.
Bridges in cold regions – Northern Europe, Canada, Russia.
Wind turbine towers – Fatigue resistance + low temperature.
Offshore structures.
Mechanical Properties – Side by Side (Data Table)
| Property | P355GH | S355J2 | Winner |
| Yield Strength (≤16mm) | ≥ 355 MPa | ≥ 355 MPa | Tie |
| Tensile Strength (≤16mm) | 510 – 650 MPa | 470 – 630 MPa | P355GH (higher minimum) |
| Impact Test Temperature | 0°C (≥ 34J) | -20°C (≥ 27J) | S355J2 for low temp; P355GH for room/high temp |
| High Temperature (400°C) | Excellent (Designed for creep resistance) | Poor (Strength drops rapidly) | P355GH |
| Delivery Condition | Normalized (N) mandatory | As-rolled or normalized | P355GH (more stable grain structure) |
